antiseismic building materials TRIBOPRESS are antiseismic materials of higher strength and quality ...

Antiseismic building materials TRIBOPRESS represent a completely new revolutionary category of building materials of exceptional quality and strength. Unlike other materials, these materials have a system of horizontal and vertical "locks". All the edges of these materials are chamfered. The system of "locks" and chamfers are formed in the process of tribo-hyperpressing (bilateral compression). These materials are used in brickwork according to the constructor "LEGO" system, making earth-quake and explosion resistant buildings.

These materials do not lose their original appearance for years. They have an exclusive demand in the building materials market, especially in the regions of high seismic and terrorist activities, and the selling price of these materilas is much higher than that of the traditional building materials.

inside antiseismic brick

This is a completely new product of the tribo-hyperpressing technology from the category of antiseismic bricks. It is innovative because of the round lobes and cavities on the horizontal (big) sides of the brick that form a system of horizontal "locks" - "male-female" system, and also because of the special geometry of all the vertical sides of the brick (the big and and the small ones) that form a system of vertical "locks" in combination with mortar. The vertical sides of the brick have semicircular chamfers (a radius of 3 mm ). The horizontal sides are decorated with a fame (2 mm thick).

The horizontal joint in brick laying is 2 mm thick, the vertical joint is 2-8 mm. Its geometrical dimensions are:

length - 258 mm, width - 128 mm, height - 65-120 mm

Tribo-hyperpressing technology provides height stability of the antiseismic brick (within 0,3 mm), that has a positive effect on the constancy of the brickwork joint (2 mm) in brick laying.

The manufacturing of the horizontal and vertical "locks", frame and chamfers provides almost an ideal repetition of their geometrical dimensions, completely excluding manual operations. Having almost the same production cost as the traditional brick, the antiseismic brick is in a greater demand in the building materials market and its selling price is 80-100% higher.

header facing antiseismic brick

This is a completely new product of the tribo-hyperpressing technology which belongs to the category of outside antiseismic bricks. Just one of the two small sides is smooth, which forms the facade. All the other characteristics and dimensions are the same as those of the previous type of antiseismic bricks.













long facing antiseismic brick

This is a completely new product of the tribo-hyperpressing technology from the category of outside antiseismic bricks. Just one of the two long sides is smooth, which forms the facade. All the other characteristics and dimensions are the same as those of the previous type of antiseismic bricks.











angle facing antiseismic brick

This is a completely new product of the tribo-hyperpressing technology from the category of outside antiseismic bricks. Two of its sides (the long and the small one) are smooth, which form the corner of the facade. All the other characteristics and dimensions are the same as those of the previous type of antiseismic bricks.











4-veneer rock face preform

This is a completely new product of the tribo-hyperpressing technology from the category of facade rock face materials with a unique relief. This facing material in a rustic stile is decorated along the perimeter with a splay (a height of 4 mm) and semicircular chamfers (a radius of 5 mm). Its geometrical dimensions are:

length - 250 mm, width - 140 mm (35 mm x 4), height - 50-140 mm

The manufacturing of the facing rock face veneer is subdivided into two stages:

  • manufacturing of the preform consisting of 4 rock face veneers
  • manufacturing of the same rock face veneers (4 at a time) by splitting the preform


The production of the preforms of 4 future rock face veneers is carried out on the same press where the bricks and the veneers are produced. The manufacturing of splays and semicircular chamfers along the perimeter of the future rock face veneers provides almost an ideal repetition of their geometrical dimensions, completely excluding manual operations.



These rock face veneers can be made either with the help of some manual device or with the help of a special hydraulic press (8 veneers at a time). In the second case, no additional operations with the veneers are necessary after splitting.

Having the same production cost as a rectangular brick, a preform of four rock face veneers with chamfers and splays along the face perimeter of the future rock face veneers is in a greater demand in the building materials market and its selling price is 70-80% higher than that of the bricks without chamfers. The transportation of the preforms is more comfortable than that of the ready veneers. It is just necessary to split them into four veneers by a manual device.

shaped antiseismic sidewalk and road pavers

This is a new product of the tribo-hyperpressing technology from the category of antiseismic paving materials. It is innovative because of the frame (2 mm thick) and semicircular chamfers (with a radius of 3 mm) along the perimeter of the three sides of the paver. Its geometrical dimentions are:

length - 250 mm, width - 120 mm, height - 40-120 mm

antiseismic building materials
